Ultra
Ultra 9/9 EV
Ultra 9/9 EV
Ultra 9/9 EV
Engine
High Head Rest/Hi Back Reclining/Push Back Seats
No. Of Seats
4920 Mm
Wheelbase
EV
Fuel Type
Staff & Contract Buses
Application
Ultra 9/9 EV
Features
Power Of 6
Benefits
-
Sturdy built quality for passenger & Drivery Safety
-
More reliable, Better performance, More profits to customers
-
Increased number of seats and seat width for seating comfort
-
More no of Trips with highest Fluid Economy
-
Refreshed look, End customer preference
-
Increased comfort and convenience to passengers
-
Better Resale value
-
Low Noise, Vibration & Harshness
-
Low Maintenance with value added service options
-
24x7 customer care and road side assistance
-
Spare Part Availability across country
Specifications
- GVW11500 kg
- Overall Length9200 mm + 50 mm
- Wheelbase4920 mm
- Overall Height3230 mm + 50 mm
- Floor Height900 mm
- Overall Width2340 mm (without mirrors)
- Passenger Door1 or 2 as per requirement
- Turning circle Diameter16.9 m
- LV System Voltage24 V
- Tyres245/70 R17.5 7 nos.
- BrakesFront Disc and Rear Drum
- SuspensionAir Suspension
- SteeringIntegral Hydraulic Power Assisted
- Traction Motor Peak power215 kW
- Traction Motor Continuous Power145 kW
- Traction Motor Peak Torque2200 Nm
- Traction Motor Continuous Torque1273 Nm
- HV Battery657 V DC
- Battery Energy200 kWh
- TransmissionDirect Drive
- ChargerOff board charging, CCS 2 Charging Standard
- Max Speed75 kmph
- Gradeability18%
- AccelerationAs per CMVR
- Seating capacity34/31/23
- Seating Layout2x2, 2x1
- Seat TypeHigh Head Rest/Hi Back Reclining/Push Back Seats
- Regulatory Requirements / CompliancesAIS - 052, FAME, CMVR
